DAQObject Class Reference

Basic DAQ object super class. More...

Inheritance diagram for DAQObject::

List of all members.

Public Methods
	~DAQObject ()
	Basic destructor. More...
int	GetType ()
	Return object type of object. More...
const char *	GetTypeString ()
	Return stringification of the object type id. More...
void	SetType (int)
	Set the object type of the object. More...
void	SetType ()
	Set the object type to the current object type. More...
unsigned int	alarm (unsigned int)
	Override alarm function. More...
daqsighandler_t	signal (int, daqsighandler_t)
	Override signal function. More...
virtual int	operator== (const char *) const
	Equality with char*. Good for testing against NULL. More...
virtual int	operator== (const DAQObject &) const
	Equality with a DAQObject. More...
virtual bool	IsNull ()
	Return true if object is null. More...
virtual void	Nullify ()
	Nullify this object. More...
virtual ostream &	Print (ostream &)
	Print this object to an ostream. More...
virtual void	PrintEyeCatcher (ostream &)
	Print an eye catcher to an ostream. More...
virtual void	Dump (ostream &)
	Dump this object to an ostream. More...
Basic_OStream_Iface &	Print (Basic_OStream_Iface &)
	Print this object to a Basic_OStream_Iface. More...
void	Dump (Basic_OStream_Iface &)
	Dump this object to a Basic_OStream_Iface object. More...
Protected Methods
	DAQObject ()
	Basic Constructor. More...
Friends
class	DAQTrackMap

---

Detailed Description

The DAQObject class is a super class from which nearly all other DAQ classes inherit. This class provides some basic functionality and support for tracking object creation. Some basic C/C++ functions are overridden in this class.

Author:

Eric Kasten

Version:

0.4.0

---

Constructor & Destructor Documentation

DAQObject::~DAQObject (  )

Basic destructor method. Parameters: None   Returns: None

DAQObject::DAQObject (  )  [protected]

Basic constructor method. Parameters: None   Returns: this

---

Member Function Documentation

void DAQObject::Dump (  Basic_OStream_Iface & aStream )

Dump this to a object that implements Basic_OStream_Iface interface. For a DAQObject this simply prints the type id and stringification. Parameters: aStream   A Basic_OStream_Iface object for printing Returns: None

void DAQObject::Dump (  ostream & aStream )  [virtual]

Dump this to an ostream. For a DAQObject this simply prints the type id and stringification. Parameters: aStream   An ostream for printing Returns: None

int DAQObject::GetType (  )

Get the type id of this object as previously set using SetType(). Parameters: None   Returns: The integer type id of this object.

const char * DAQObject::GetTypeString (  )

Get a string (char*) representation of the object type for this. Parameters: None   Returns: The stringification of the type id

bool DAQObject::IsNull (  )  [virtual]

Determine if this object is considered a null object (from a meta standpoint -- that is, the object exists but is considered to be an object of a null type). Parameters: None   Returns: Whether this object is considered null Return values: true   The object is considered null false   The object isn't considered null

void DAQObject::Nullify (  )  [virtual]

Make this a null object. That is IsNull() will return true once Nullify() is called on this. Parameters: None   Returns: None

Basic_OStream_Iface & DAQObject::Print (  Basic_OStream_Iface & aStream )

Print a stringified representation of this to an object that implements the Basic_OStream_Iface interface. Parameters: aStream   A Basic_OStream_Iface object for printing Returns: The Basic_OStream_Iface object

ostream & DAQObject::Print (  ostream & aStream )  [virtual]

Print a stringified representation of this to an ostream. Parameters: aStream   An ostream for printing Returns: The ostream Reimplemented from Printable. Reimplemented in DAQNodeId, and DAQThreadId.

void DAQObject::PrintEyeCatcher (  ostream & aStream )  [virtual]

Print an eye catcher. Note that you can't create any new objects that might actually get added to the daq_tracker in this method or any methods derived from this method. Doing so tends to create deadlocks due to the locking nature of the daq_tracker. This method does very little (i.e. it prints nothing for a DAQObject). Override for better use. Parameters: aStream   The ostream for printing Returns: None Reimplemented in DAQThreadMutex, and DAQThreadRecursiveMutex.

void DAQObject::SetType (  )

Reset the type id of this to one set previously. This is mainly used during bootstrapping. Parameters: None   Returns: None

void DAQObject::SetType (  int t )

DAQ objects can be typed so that they can be tracked at runtime. By default, all objects derived from a DAQObject are of type DAQObject. Derived classes can choose to provide a more informative type id by using this method to set their type. This has nothing to do with rtt. At this time, the system needs to have a type id entered into a compile time table for this. Parameters: t   A type id for this. Returns: None Todo: Add dynamic type additions

unsigned int DAQObject::alarm (  unsigned int aVal )

Override the standard C alarm() function. Throws an exception if it appears the alarm is already in use. Parameters: aVal   The number of seconds to wait for the alarm Returns: See alarm(2)

int DAQObject::operator== (  const DAQObject & v )  const [virtual]

Equality with DAQObject. Really just checks to make sure the object types are identical. Override if you want more functionality! Parameters: v   A DAQObject for comparison. Returns: If this object is type equivalent to v Return values: 0   This object isn't type equivalent 1   This object is type equivalent

int DAQObject::operator== (  const char * s )  const [virtual]

Check if this can be considered equal to NULL. That is, This object must have a type of DAQObject and both (v == NULL) and IsNull() must be true. Parameters: v   Character pointer Returns: If this object can be considered equal to NULL Return values: 0   This object isn't considered equal to NULL 1   This object is considered equal to NULL

daqsighandler_t DAQObject::signal (  int signum, daqsighandler_t handler )

Over the standard C signal() function. Throws an exception if an error is return from the call to signal(). Parameters: signum   The signal number handler   A signal handle function Returns: The signal handler or error (see signal(2))

---

The documentation for this class was generated from the following files:

• DAQObject.cc
• DAQObject.h

---
